The diagram below shows how electricity is generated in a hydroelectric power station.
The provided diagram showcases the process of electricity production in a hydroelectric power station, which is initiated by the flow of
water
from the river into a high-level reservoir
and ends with the transmission of electricity to the national grid.
During the day, water
flows down the river to reach a high-level water
storage facility that features a dam
. The water
then
passes through the intake of the dam
, after which it moves towards the hydropower station. The turbines at the hydropower station are activated, and the water
turns them to generate power that is
subsequently
supplied to the National Grid. Finally
, the water
is stored in a low-level reservoir
at the end
of the daytime.
The night operation begins by reversing the turbines and pumping the water
from the low-level reservoir
. This
water
is then
directed towards the dam
and transported to the high-level reservoir
. It is important to note that the intake to the dam
remains closed, ensuring that all the water
is retained in the high-level reservoir
.Submitted by sun1286908654 on
